Product name | License Plate Recognition Machine |
Working voltage | AC220V±10% |
Working temperature | -25℃~+70℃ |
Relative humidity | ≤95%, no condensation (at room temperature) |
Rated power | 60W |
Communication method | TCP/485 |
LED display | 4-line display |
Enclosure protection level | IP54 |
Chassis material | 1.2mm thick high-strength steel plate, 4mm tempered glass |
Chassis process | Sheet metal mold molding, spray color gold |
Dimensions and specifications | 355*152*1365mm (length*width*height) |
Power supply | 12V—2A |
Maximum power consumption | 15W |
Protection level | IP66 |
Communication connection method | SDK, ONVIF, HTTP, RTSP, TCP, RS485, IO |
License plate recognition rate | ≥99% |
Adaptive speed range | 0-40 km/h |
Recognition angle | ≤45° |
Image sensor | 1/2.7″ CMOS or 1/2.8″ CMOS |
Trigger type | Coil or video |
Resolution | 1920x1080dpi |
Optimal recognition distance | 3-6 meters |
Frame rate | 25 frames/second |
Output information | Vehicle feature image, license plate image, license plate number, color, type, passing time |
Output image format | JPEG |
Output video format | H.264 |
Storage | Expandable microSD Card |
Manually restore factory settings | Reset |
Fill light | Built-in 4 fill lights, adjustable brightness (maximum power consumption of a single light is 1W) |
Lens | Electric zoom or 6mm fixed focus |
Number of lamp beads | 12 LED lights |
Power | 12W |
On/off control | Photosensitive control settings |
Fill light distance | Lighting greater than 50LUX at 5m |
Adjust angle | 3D universal adjustable, adjustment range 20 degrees |
When obtaining an ANPR system, several factors should be considered. The following guidelines can assist in making an informed decision:
By carefully considering these factors, individuals or organizations can select an ANPR system that aligns with their specific requirements and maximizes the benefits for their intended application.
