Professional GPS Tracker with fleet management solution Jimi VG03

Product Description

Driving Behavior Analysis (Basic)

Receive alerts when any of 4 kinds of dangerous driving behavior is detected.

IP65 Dust & Water Resistance

Rugged design ensures continued optimal performance, even in the toughest conditions.

Remote Cut-Off (Fuel/Power)

Immobilize a vehicle by cutting off its power source/fuel supply via an installed relay.

Ignition Detection

Constantly detect the ACC/ignition status of the vehicle.

Geo-fence

A virtual area set on platform by yourself, you’ll be informed when vehicle crossing its boundary.

Multiple Alerts

Instant alerts for atypical events such as low battery, speeding, removal, drifting, etc.

Multiple Alerts

Technical Parameter:�

Specifications
Weight	38g
Dimensions	78 (L) × 41(W) × 13 (H) mm
Working voltage / current	9-90vDC / 7mA
Operating temperature	-20℃ – 70℃
Operating humidity	20% to 80% non-condensing
LED indicator	3 LED indicator: GPS-blue, GSM-green, Power-red
GSM	850 / 900 / 1800 / 1900 MHz
GPRS	Class12, TCP/ IP build in GSM Module
GPS	MT3336
Frequency	L1, 1575.42MHz C/A code
GSM antenna	Built-in quad band
GPS antenna	Built-in GPS high gain ceramics patch antenna.
GPS Channels	66
Tracking sensitivity	-165dBm
Acquisition sensitivity	-148dBm
GPS starting time	Hot start: < 2 sec(open sky)
GPS starting time	Cold start: <45 sec(open sky)
Battery	3.7vDC / 270mAh
Working hours	3.6 hours
GPS Position Accuracy	<10m
Data Transmit	TCP, SMS
Geo-fence Alarm	support
Over speed Alarm	support
Low Power Alarm	support
Movement Detection	support
Mileage Report	support
Remote Control petrol/electronicity	support
Vibration alarm	support
History playback	Support 3 months
APP System support	Ios and Android
